Legion Slide Voltage Switching Switches Performance Parameters - Rated Current/Voltage: Multiple specifications available, such as 6A 125/250VAC, 10A 125VAC, etc. - Initial Contact Resistance: <30mΩ - Insulation Resistance: >100MΩ - Withstand Voltage: 5mA 1500VAC/min - Electrical Life: At least 10,000 cycles Material Composition - Housing: Usually made of PC flame-retardant material, with excellent flame resistance and mechanical strength to prevent fire and protect internal circuits. - Slide Handle: Generally plastic (e.g., PBT with glass fiber), offering good wear resistance and insulation for safe and easy operation. - Contact Parts: Switches often use eco-friendly composite silver contacts for high conductivity, arc resistance, and oxidation resistance, extending service life. - Spring: Made of stainless steel or bronze to provide stable elasticity, ensuring reliable contact and disconnection of terminals. - Terminal Blocks: Typically copper-based, with tin or silver plating to enhance conductivity and oxidation resistance.
