Application Fields of LEGION Pushbutton Power Switch
- Household Appliances: Used for power on/off control in high-power small appliances like humidifiers, electric heaters, and DVD players. - Industrial Equipment: Applied as power switches to start and stop various industrial devices. - Electronic & Digital Products: Widely used in computer power supplies, power strips, copiers, fax machines, and other electronic devices. Electrical Performance
- Contact Resistance: Measured at DC 0.2V/1A, the contact resistance is <20mΩ. - Insulation Resistance: Tested at DC 500V for open-circuited terminals, the insulation resistance is >100MΩ. - Withstand Voltage: - Between open terminals of different poles: 1000VAC for 1 minute. - Between terminals and metal casing: 3000VAC for 1 minute. - Life Test: Example: Withstand 9,800 cycles at 250VAC/80A (PF=0.95), 30 cycles/min.
